JIC Adapters/

2TJ-SP JIC Female Hydraulic Hose Fitting

BSPT MALE / JIC FEMALE 74° SEAT



Model:2TJ-SP

Own Brand:Gemco

Executive Standard:Parker Standard

Optional Material:Carbon steel, 304, 316

Thread Form:Metric, US, Imperial

Stripping Form:NO-SKIVE

Fitting Advantage:Simple and easy to operate, reduce labor costs

  • Product Details

GEMCO is a hydraulic system products factory integrating R&D, production, wholesale and sales. It provides the production, testing and delivery of high pressure ball valves hydraulic hoses assembly, quick coupling, connectors, assemblies and other industrial partes for various hydraulic demand fields domestic and abroad. One-stop service with high quality and fast delivery is available.



PART NO. THREAD DIMENSIONS
E F   B L S1 S2
2TJ-02-04SP R1/8”X28 7/16”X20 10 9 24 12 17
2TJ-04SP R1/4”X19 7/16”X20 14 9 28 14 17
2TJ-04-05SP R1/4”X19 1/2”X20 14 9 28.5 14 17
2TJ-04-06SP R1/4”X19 9/16”X18 14 10.5 28.5 14 19
2TJ-06-05SP R3/8”X19 1/2”X20 15 9 29.5 17 17
2TJ-06SP R3/8”X19 9/16”X18 15 10.5 29.5 17 19
2TJ-06-08SP R3/8”X19 3/4”X16 15 10.5 31.5 19 24
2TJ-08SP R1/2”X14 3/4”X16 19 10.5 37.5 24 24
2TJ-08-10SP R1/2”X14 7/8”X14 19 12 38 24 27
2TJ-08-12SP R1/2”X14 1.1/16”X12 20 15 41.5 27 32
2TJ-12SP R3/4”X14 1.1/16”X12 19 15 41.5 30 32
2TJ-12-16SP R3/4”X14 1.5/16”X12 20 16 43.5 32 41
2TJ-16SP R1”X11 1.5/16”X12 24 16 47.5 36 41
2TJ-20SP R1.1/4”X11 1.5/8”X12 25 17 55 46 50
2TJ-24SP R1.1/2”X11 1.7/8”X12 26.5 20 59.5 50 55
